Magnetic front maintenance design: With magnetic modular structure, there is no need to disassemble the entire screen or rear bracket. The single module can be directly removed from the front by adsorption, which greatly simplifies the maintenance process.
Lightweight design: The aluminum cabinet shell is light and strong, reducing the overall weight, facilitating installation and maintenance, while maintaining high strength and durability.
Right-angle and corner design: Supports flexible installation methods, can adapt to different scene requirements, especially suitable for complex installation environments that require right-angle or corner splicing, to achieve seamless splicing effects.
Technical Parameter | |||||
Pixel Pitch | P1.25 | P1.538 | P1.86 | P2 | P2.5 |
Module Size | 320*160mm | ||||
Cabinet Size | 640*480*65 | ||||
Cabinet Density | 640000dot/㎡ | 422754dot/㎡ | 289051dot/㎡ | 250000dot/㎡ | 160000dot/㎡ |
LED Configuration | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD1515 SMD2020 |
Brightness | 600cd/㎡ | 600cd/㎡ | 600cd/㎡ | 600cd/㎡ | 800cd/㎡ |
